Join together! - Voo Duplo (biplace)
Who can't remember the rush of the first time?
The first time taking off, of course! To be free, to fly, to feel like a bird. With the JOIN'T, flying pleasure doubles instantly!
Projetado e construído para uso pessoal ou profissional!
Segurança é o quesito mais importante quando desenvolvemos um parapente para vôo duplo.
Mais de 2 anos de desenvolvimento, uma infinidade de protótipos e testes tornaram o Skywalk JOIN'T2 realidade.
Excelente comportamento na decolagem, pilotagem fácil e amigável, larga margem de segurança passiva e tecnologia Jet Flap: estas são as principais característica s procuradas por pilotos de vôo duplo.
The JOIN'T2 impresses further with competent material selection and numerous new detailed solutions. Naturally, the JOIN’T2 also offers excellent handling and premier league performance.
- Extremely robust and durable NCV 9092E85 cloth is used on the crucial leading edge of the top sail. Despite the first-class durability, the JOIN’T2 still has a low weight.
- Continuous profile reinforcement bands on the profile and the load-oriented function of the connection points provide maximal stability even after hard use
- The hybrid lines, consisting of a mix of Tecnora and Dyneema lines, provide for uniform trim even after intensive use
- The JOIN’T2 is equipped with sophisticated risers and integrated speed trimmers, ensuring easy handling and a wide range of use
Veja algumas fotos do Join't Skywalk
Cores disponíveis
Ficha Técnica
JOIN'T | AR | BI |
---|---|---|
Número de células | 44 | 44 |
Área (sqm) | 39,07 | 42,3 |
Area (projected) | 18,7 | 21,3 |
Wingspan [m] | 13,78 | 14,34 |
Aspect ratio | 4,86 | 4,86 |
Area projected [qm] | 34,41 | 34,41 |
Wingspan projected [qm] | 11,22 | 11,68 |
Aspect ratio projected | 3,66 | 3,66 |
Line length [cm] | 79,7 | 83 |
Line diameter [mm] | 1,2/1,5/2,2 | 1,2/1,5/2,2 |
Cord max. [cm] | 351 | 366 |
Cord min. [cm] | 73 | 76 |
Canopy weight [kg] | 9,6 | 10,4 |
Cert. Take-off-weight* [kg] * Pilot + 17 kg equipment |
115-190 | 140-230 |
Manual:
Clique aqui para baixar o manual do parapente Skywalk Join´t
Plano de linhas:
Clique aqui para baixar o plano de linhas do parapente Skywalk Join´t
Teste de certificação LTF09/EN:
Clique aqui para baixar o teste de certificação LTF
